Patch cord fibra optica multimode OM4 50/125μm, conform standardelor ISO/IEC 11801 si TIA-568-C.3, cu manta LSZH, culoare violet (sau aqua), duplex sau simplex, disponibil in diferite combinatii de conectori (SC, LC, E2000, ST, FC, MU, MTRJ), polish (UPC) si lungimi.
Patch cord-urile FO OM4 sunt utilizate in transmisii 10G/25G/40G/100G, fiind ideale pentru centre de date si retele de mare viteza, cu lungimi de unda de 850nm si 1300nm si distante de pana la 550m pentru 10G Ethernet.
Caracteristici:
| Tip | Multimode OM4 50/125μm (ISO/IEC 11801, TIA-568-C.3) | Manta | culoare violet (sau aqua) tip LSZH grosime 2mm/3mm |
| Pierderi la retur | UPC≥20 | Atenuare | @ 850nm: ≤2.3dB/km @ 1300nm: ≤0.6dB/km |
| Pierderi la insertie | UPC≤0.3 | Ferula conector | zirconiu ceramica |
| Polaritate | A(Tx) – B(Rx) | Temp de functionare | -20⁰C ~ +70⁰C |
| Rezistenta la intindere | 150N (termen lung) – 300N (termen scurt) | Rezistenta la impact | 2500 N/dm |
| Part No. | Nr. fibre | Conector A | Conector B | Manta | Lungime | Tip Fibra |
| PCH1.OM4-LC/LC-xx-x.0 | Simplex | LC/UPC | LC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH2.OM4-LC/LC-xx-x.0 | Duplex | LC/UPC | LC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH1.OM4-SC/LC-xx-x.0 | Simplex | SC/UPC | LC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH2.OM4-SC/LC-xx-x.0 | Duplex | SC/UPC | LC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH1.OM4-SC/SC-xx-x.0 | Simplex | SC/UPC | SC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH2.OM4-SC/SC-xx-x.0 | Duplex | SC/UPC | SC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH1.OM4-E2K/LC-xx-x.0 | Simplex | E2000/UPC | LC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH2.OM4-E2K/LC-xx-x.0 | Duplex | E2000/UPC | LC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH1.OM4-E2K/SC-xx-x.0 | Simplex | E2000/UPC | SC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH2.OM4-E2K/SC-xx-x.0 | Duplex | E2000/UPC | SC/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH1.OM4-E2K/E2K-xx-x.0 | Simplex | E2000/UPC | E2000/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
| PCH2.OM4-E2K/E2K-xx-x.0 | Duplex | E2000/UPC | E2000/UPC | LSZH 2.0mm/3.0mm | 0.25m – 100m | MM OM4 50/125μm G.651 |
Note:
xx – reprezinta lungimea patchcordului (de exemplu 1 reprezinta 1m, 10 reprezinta 10m).
x.0 – reprezinta grosimea mantalei…2.0 reprezinta 2mm iar 3.0 reprezinta 3mm.
• Ideal pentru centre de date si retele enterprise, unde sunt necesare conexiuni de mare viteza si performanta ridicata.
• Utilizat in sisteme de stocare SAN/NAS si aplicatii critice de analiza de date, oferind latenta redusa si transfer rapid.
• Recomandat pentru retele LAN de mare capacitate, permitand transmisii de 10G/25G/40G/100G Ethernet pe distante extinse fata de OM3.
• Potrivit pentru conectarea echipamentelor din aceeasi cladire sau campusuri, oferind eficienta si fiabilitate ridicata.
• Excelent pentru aplicatii de cloud computing si virtualizare, unde este necesara o infrastructura stabila si scalabila.
• O solutie ideala pentru sisteme de afisare digitala si transmisii video 4K/8K, datorita capacitatii sale mari de banda.
• Adecvat pentru retele de supraveghere si infrastructuri IoT, asigurand conexiuni rapide si stabile intre dispozitive.
